GE OEC 6800 MiniView Mini C-Arm

Category:

The GE OEC 6800 MiniView is one of the most popular mini c-arms in the world – and for good reason. This GE Mini C-Arm incorporates the workstation components of GE’s full-sized OEC 9800 Plus c-arm at a cost-effective price. The OEC 6800 MiniView is effectively used by hand surgeons, podiatrists, orthopedics and rehabilitation services. Highlights include:

  • Superb Images – 50-micron focal spot captures the finest anatomical detail
  • Immediate Results – Fully-digital 1k x 1k, 16-bit image processing with real-time edge enhancement
  • Unsurpassed Viewing – 19-inch diagonal dual monitors and selectable image size provide a highly flexible viewing area
  • Intuitive Touchscreen – Advanced digital image processing aids patient annotation, archive and review
  • Expanded Archiving – Up to 800 images saved in memory of 2000 images of removable media

Buy / Sell All Models

GE OEC 6800 Specifications
Generator:
  • Compact Mono Block Design
  • High Frequency, 20kHz
X-Ray Tube:
  • Stationary Anode
  • 0.25 mm Focal Spot
Fluoroscopy:
  • kVp Range: 40-75
  • Micro Amp range: 20-100
  • Auto technique control (ABS)
  • Manual technique control
  • Auto & Manual Brightness/Contrast

Imaging Specifications
Image Intensifier:
  • High Resolution, High contras conventional cesium iodide design
  • 6″/4″ Dual Mode image intensifier
TV Camera:
  • High Resolution 1K X 1K CCD Camera
Image Display:
  • Dual 1K X 1K Monitors
  • Fast Scan flicker free
  • Anti-Glare, Anti-Static
  • Auto adjusts to room ambient light
  • 360 degree image rotation motorized
  • Left- Right image reversal
  • Auto Swap
  • Auto Save
  • X-Ray Dose Summary
  • Touch Screen User Interface
Image Memory:
  • Last image hold
  • Real time averaging
  • One shot frame integration
  • MARS (motion artifact reduction)
  • Auto digital brightness and contrast adjustments
  • Edge enhancements
  • Negate
  • Patient annotation keyboard

Software
Software Platforms
  • HP – Hospital Platform
  • CP – Clinical Platform

Physical Specifications
C-Arm Specifications:
  • Free Space: 12″
  • Depth: 14.5″
  • SID: 14.9″
  • Orbit Rotation: 110°
  • Rotation: +/- 200°
  • Wig-Wag: 180°
  • Vertical Travel: 24″
  • Extension: Up to 55″
C-Arm Dimensions:
  • Height: 64″
  • Width: 27″
  • Depth: 27″
  • Footprint: 5 Sq.ft
Power Requirements:
  • Input power: 60Hz
  • 100-120V 15A
  • 200-240V 8A
